BMW M8 WEC GTE and IMSA GTLM for 2018 season

BMW M8 GTE and IMSA GTLM for 2018 season

Frankfurt September 12th 2017 . BMW Motorsport presented its new top-of-the-range model for the international GT racing scene at the International Motor Show (IAA) in Frankfurt am Main: the BMW M8 GTE. Before the BMW 8 Series Coupé goes on sale, the race car will compete on the track next season, including in the FIA World Endurance Championship (FIA WEC). It is with this series that BMW Motorsport will also make its return to the iconic 24 Hours of Le Mans (FRA). As such, the BMW M8 GTE will be associated with both innovative, cutting-edge technology and decades of motorsport tradition. At the IAA, the new car was on display in a BMW M Motorsport livery, designed especially for this occasion, providing a visual taste of things to come in 2018. It reflects the close relationship between the development of production vehicles and motorsport, and once again underlines the degree, to which BMW Motorsport and BMW M belong together.

BMW M8 GTE and IMSA GTLM for 2018 season

The close link between production and motor racing is one of the cornerstones of the development of the BMW M8 GTE. The knowledge gained from race outings with the new car in the FIA WEC and the IMSA WeatherTech SportsCar Championship (IWSC) in North America will be directly incorporated in the development of the production model, which is running parallel to the motorsport project.

“The BMW M8 GTE is our new GT flagship and will go head to head with the strong opposition in this sector,” said BMW Motorsport Director Jens Marquardt. “For us, the presentation of the uncamouflaged car at the IAA is the next important step on the road to our first race outing, which we plan to be the 24 Hours of Daytona in 2018. The FIA WEC and the IMSA series in North America are a top competitive environment for our new challenger. With the BMW M8 GTE, we are bringing cutting-edge technology to the top international class of GT racing, whilst at the same time tying in with our tradition at Le Mans. The development of the BMW M8 GTE is on schedule, and we can hardly wait to see the car challenging for victories in 2018.”

BMW M8 GTE and IMSA GTLM for 2018 season

 The V8 engine with BMW TwinPower Turbo Technology, which is restricted by regulations to a capacity of 4.0 litres, has a nominal base output of more than 500 hp, depending on the classification. The cylinder block and cylinder head are taken from the production engine and are produced in the light alloy foundry at the BMW Group plant in Landshut (GER). The focus of the development work is on achieving the greatest possible efficiency and maximum durability. The powerful production engine provides the perfect basis. The power transmission in the BMW M8 GTE takes place via a sequential, six-speed racing gearbox.

Racing and production engineers closely worked together within the framework of the BMW M8 GTE project. For instance, consistent lightweight design also plays a crucial role in the development of the new GT sports car. A significant weight reduction is achieved through the extensive use of ultra-light CFRP components. At a length of 4,980 mm and a width of 2,046 mm, the car weighs just 1,220 kilograms. The design of the BMW M8 GTE also reflects the close relationship to the BMW 8 Series and the BMW M8. This is particularly apparent in the same roof line and the design of the front and rear lights.

BMW M8 GTE and IMSA GTLM for 2018 season

Peak performance in aerodynamics development.


Work on the aerodynamics of a new race car is as time-consuming as it is indispensable. As such, it is all the more important for the BMW engineers to be able to work on the chassis of the BMW M8 GTE with maximum efficiency from the outset. A new algorithm allows a significant increase in CFD calculations, thus making it possible to use greater computing power to clearly increase the number of possible simulations, before progressing to the wind tunnel. Here, BMW Motorsport uses synergies with production development and benefits from the perfect test conditions in the BMW Group Aero Lab. One of the results of the aero development is innovative aero rims, which will be presented as a concept at the IAA.

The close interdependence between production and motorsport development continues in another two important areas: the same 3D measurement technology that was used on the BMW M4 DTM, which made its first race outing in 2017, is also used on the BMW M8 GTE. The ultra-modern measurement system from the BMW production development department provides the perfect quality control once the race car has been assembled. With such a complex car as the BMW M8 GTE, which is built completely by hand, it is essential that all the dimensions are correctly adhered to and implemented

BMW M8 GTE and IMSA GTLM for 2018 season
1999 BMW V12 LMR Le Mans 24 Hours Winner

Long history of BMW Motorsport in Le Mans.


BMW Motorsport returns to Le Mans with the FIA WEC in 2018. The last time a BMW race car featured on the grid was back in 2011, with the BMW M3 GT2. One year prior to that, the Jeff Koons’ (USA) BMW M3 GT2 Art Car had caught the eye, as it wrote the latest chapter in the story of the BMW Art Car Collection at Le Mans. Among the BMW Art Cars that had started previously at Le Mans were Alexander Calder’s (USA, 1975) BMW 3.0 CSL, the BMW 320i designed by Roy Lichtenstein (USA, 1977) and Andy Warhol’s (USA, 1979) BMW M1.

BMW Motorsport’s greatest sporting hour in Le Mans came in 1999, when Yannick Dalmas (FRA), Joachim Winkelhock (GER) and Pierluigi Martini (ITA) took overall victory in a BMW V12 LMR. The McLaren F1 GTR, powered by a BMW engine, had previously triumphed at the “Circuit de la Sarthe” in 1995.

The first time a BMW car started at the 24 Hours of Le Mans was back in 1939, when a BMW 328 claimed a class victory after 236 laps of racing. After 1972, BMW cars regularly lined up at the endurance classic.

BMW M8 GTE and IMSA GTLM for 2018 season

Dimensions

Length without rear wing

4,980 mm

Width without mirrors

2,046 mm

Width with mirrors

2,224 mm

Height

1,212 mm (variable)

Wheelbase

2,880 mm

Engine

Model

V8 engine with BMW TwinPower Turbo Technology

Capacity

3,981 cc

Number of cylinders

8

V angle

90°

Bore/ Stroke/ Cylinder spacing

89 mm/ 80 mm/98 mm

Engine speed

Approx. 7,000 rpm

Body

Type

Composite body with carbon core and DMSB approved safety roll cage CFRP outer shell with quick change concept

Chassis

Suspension

Double wishbones on front and rear axle
Four way adjustable shock absorbers at front and rear
Anti-roll bars with quick adjustments

Power transmission

Six speed sequential motorsport gearbox
Electric paddle shift system
CFRP dive shaft
Limited slip differential
 Sachs carbon fiber clutch

Electronics

BMW Motorsport in house developed software functions for engine, gearbox and driver assistance
Steering wheel with 16 buttons and seven dials
Rear view camera system with object recognition
High performance headlights with OSRAM LED elements
Live telemetry system for vehicle monitoring

Wheels/Tyres

BMW Aero rims 12.5x18 inch on the front axle, 13x18 inch on the rear axle



Michelin tyres 30/68 R18 on the front axle; 31/71 R18 on the rear axle



BMW M8 GTE and IMSA GTLM for 2018 season

P.Damiens-information and illustrations BMW Motorsports Media Archives and NEWSPRESS
